1T DC/24V Full Electric Stacker Trolley with 3m Lifting Height cost
Specification
Productivity & Efficiency
1. Side loaded battery compartment for quick & easy battery replacement.
2. Two and three stage mast options satisfy different lift and lowered height demands
to fit the unique requirements of an application.
3. Electric power steering and platform options allow for additional operating
Serviceability
1. Quality American AMP connectors prevent moisture and contaminants from interrupting truck operation
in all environments. In addition, all the wires and cables are well protected and marked to prevent system
issues and reduce maintenance time.
2. Anti-roll back device keeps the truck from rolling backwards on ramps or inclines allowing maintenance
on uneven surfaces.
3. Main electrical components can be accessed without the need of tools.
Description
| Model | ES1030 |
| Power | Battery | Lift height(mm) | 3000mm |
| Operator type | Walkie | The height load weight(kg) | 700kg |
| Service weight(kg) | 465kg | Height lowered fork(mm) | 86mm |
| Load capacity(kg) | 1000kg | Fork length(mm) | 1150mm |
| Load center distance(mm) | 600mm | Overall length(mm)(Pedal) | 1755mm |
| Lift motor(kw) | 2.2kw | Overall width(mm) | 795mm |
| Driving motor(kw) | 0.75kw | Outside width(mm) | 570/695mm |
| Driving speed(km/h) | 5.5/5.2km/h | Single fork width(mm) | 160mm |
| Service brake | Regenerative | Fixed leg length(mm) | 928mm |
| Battery(Size) | 2*12v/100Ah(260*169*215) | Fixed keg,outiside width(mm) | 510/635mm |
| Tires | PU | Turning radius(mm) | 1336mm |
| Tyre size, front | Φ80*70,4 | The max./min.height of stacker | 3424/1994mm |
| Tyre size, rear | Φ210*70,1 | Working time(h) | 5h |
| Balance tyre | Φ150*58,1 | Lift speed,laden/unladen | 150/105 mm/s |
| | | Lowering speed,laden/unladen | 95/100 mm/s |
